Battery Charger UBC
2 D01236-14
MECHANICAL DIMENSION
200
97
115
49
65
235
N.B. All dimensions are expressed in mm.
DRILLING DETAILS
UP
Advised Installation
N.B. All dimensions are expressed in mm
Ø7
58 58
115
50
215 235
10
10
