English Battery charger UBC
8 D01236-14
TECHNICAL FEATURES
Ta=25°C unless otherwise specified.
Mains side
Description
Symbol
Test Condition
Value and/or Range
Unit
Supply Voltage
Vin - 230 ± 10%
115 ± 10%
Veff
Frequency f - 50 ÷ 60 Hz
Absorbed Maximum Current
Iin
max
P = P
max
3 @ 230 Veff
4 @ 115 Veff
Aeff
Power Factor
cosϕ
P = P
max
0,7 -
Absorbed Maximum Power
Pin
max
P = P
max
425 (230 Veff)
340 (115/230 Veff)
W
Battery side
Description
Symbol
Test Condition
Value and/or Range
Unit
Output current ripple - I = I1 < 5% -
Absorbed current I
a
Equipment turned off < 1 mA
Output voltage ripple - U = U1 < 1% -
Maximum power supplied P
max
U = U1, I = I1 360 W
Output capacity C - Depend on the model
(>1000)
µF
General
Description
Symbol
Test Condition
Value and/or Range
Unit
Operating range of temperature
∆T
- from -20 to +50 °C
Maximum relative humidity RH - 90% -
Switching frequency f
c
- 150 ± 5% kHz
Efficiency
η
At each condition > 85% -
Maximum size a×b×c Without connecting cable 235×115×65 mm
Weight - Without connecting cable 850 g
Enclosure class - - IP20 -
Protection and Safety
Description
Symbol
Test Condition
Value and/or Range
Unit
Insulation - Mains to Battery side 1250 V
AC
Insulation - Mains side to Earth 1250
V
AC
Insulation - Battery side to Earth 1250
V
AC
Leakage current I
L
Supplied equipment < 3 mA
Input fuse F1 Inside the equipment 7 (delayed) A
Output fuse F3 Inside the equipment 20 A
Minimum output voltage of operation (Battery
Detector)
- Equipment turn on 1,3 V/cell
Reverse output polarity - At the connection to the Battery Protection provided by
fuse F2
-
Thermal protection of semiconductors
(Temperature of Thermal Alarm)
- Ta=55°C 100 °C
Safety Requirements (Rules) - EN60335-1, EN60335-2-29 - -
EMC Requirements (Rules) - EN55014-1, EN61000-3-3
EN55014-2, EN61000-4-2
EN61000-4-4, EN61000-4-5
EN61000-4-6, EN61000-4-11
- -
This device is in conformity with the Low Voltage directive 2014/35/EU and EMC
directive 2014/30/EU and their further modifications.
