ZKTeco C3-100 User Manual

Connection and Installation
- 15 -
1. The auxiliary input may be connected to infrared body detectors, fire
alarms, smoke detectors, etc.
2. The auxiliary output may be connected to alarms, cameras, door bells,
etc.
3. All the terminals mentioned above are set through relevant access control
software. Please see the respective software instructions for details.
Ports on the C3 control operator panel:
No. Functional Port
C3-100
(One-Door
Two-Way)
C3-200
(Two-Door
Two-Way)
C3-400
(Four-Door
One-Way/Two-D
oor Two Way)
1
Wiegand card reader
interface
2 4 4
2 Exit button
1 2 4
3 Control lock relay
1 2 4
4 Door sensor
1 2 4
5 Extension input
× 2 4
6 Extension output
1 2 4
7
RS485 & PC
communication
√ √ √
8
RS485 extension
communication
× √ √
9 TCP/IP
√ √ √
3.5 Connection with Door Sensors, Exit Switches, and
Auxiliary Input Devices
Door sensor

ZKTeco C3-100 Specifications

General

Type	Basic access control reader
Access code reader	No
Fingerprint reader	-
Authentication type	Access chip/card
Access chip/card reader	Yes
