Control Panel User Manual
- 6 -
Auxiliary relay output: The maximum switching voltage: 36V(DC); The
maximum switching current: 1.25A
With detachable connection terminals made of alloy-steel non-magnetic flange
materials.
Outline dimensions of the control PCB: 160mm (length) × 106mm (width) for
C3-100/200; 216mm (length) × 106mm (width) for C3-400.
External box dimensions: 360mm × 285mm × 75mm.
Valve regulated lead-acid battery:
Constant voltage charge voltage regulation
Cycle use : 14.5V~14.9V(25)
Initial current: less than 2.88A
Standby use: 13.6V~13.8V(25)
Capacity: 12V, 7.2Ah/20hr,
Battery Type: LC-RA127R2T1
Battery Caution:
Do not charge in a gas tight container.
Do not short the battery terminals.
Do not incinerate
Flush with water at once if contact is made with electrolyte (Acid)
Do not attempt to disassemble the battery.
