2
How to connect the device?
Refer to the following wiring to connect the device.
Terminal Block
Exit Button, Door Sensor & Bell Connection
Exit Button
Door Sensor
Bell
BUT
GND
SEN
BELL-
BELL+
TX+
TX-
BUT
GND
SEN
BELL-
BELL+
RX-
RX+
GND
+12V
NO
COM
NC
Network
Interface
Power In
Lock
Exit Button
Sensor
Bell
