11
Figure 3
The elevation of the ZLAN5143D serial port server is shown in the figure above,
with a 35mm standard guide rail housing.
1) Power input: terminal: 5.08mm terminal. The input voltage is 9 ~ 24V.
Indicator
Power Supply
PGND
RJ45 port
NC
