Shanghai ZLAN Information Technology Co., Ltd Tel: +86-17321037177 http://www.zlmcu.com
14
Figure 5 back of the device
4.2 Hardware Connection
Generally speaking, serial port server only needs to connect power supply, serial
port and network cable.
The power supply can be configured with a 12V power adapter or a 2-wire power
supply on site, which can be directly connected to the positive and negative
terminals of the power supply.
RS485 device 485 is connected to TA, 485 is connected to TB.
The network port is connected to the ordinary network cable, which can be directly
connected to the computer or connected to the network through the switch.
4.3 Software Installation
ZLVircom can be used to configure the device IP and other parameters, also can
create virtual serial port. If no need the virtual serial port function, you can
download the free-installation version.
Table 3 ZLVircom Version
