5
General Safety
IMPORTANT SAFETY INSTRUCTIONS
DWMT24 SPECIFICATIONS
Panel Ready Dimensions
• 23 7/8" W x 24 1/2" D x 33 3/4" (min) - 35" (max) H
• 606 mm W x 622 mm D x 832 mm (min) - 889 mm (max) H
2
General Safety
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS shown throughout these
instructions. While performing installations described in this booklet, gloves and
safety glasses or goggles should be worn.
WARNING
This dishwasher comes with a heating element to heat the water. To avoid the risk of a
serious burn, don’t touch the heating element when the dishwasher is on.
WARNING
To reduce the risk of electrical shock, fire, or injury to persons, the
installer must ensure that the dishwasher is completely enclosed at
the time of installation.
IMPORTANT SAFETY INSTRUCTIONS
SPECIFICATIONS
Dimensions
(W x D x H)
• Unit with decorated door and handle: 23.9 x 26.5 x 33.7 in.
• Unit without decorated door and handle: 23.9 x 24 x 33.7 in.
Basket Handle
Top rack
Cup shelf
Tub gasket
Silverware
basket
Bottom rack
Heating
element
Rinse aid
dispenser
Detergent
dispenser
Lower spray arm
Vortex wash arm
(left side)
Spray arm
Door latch
Top light
Adjustable
upper rack
NOTE: Minimum and maximum heights take into account the legs, which can be extended
by roughly 1 1/4" (32 mm).
