14
Power Rating & Electrical Connection
ELECTRIC POWER RATING
RAIND24, RAIND30, RAIND36 SERIES RANGES
VAC 240
Plug NEMA 14-50P (50 AMP plug)
Amps 45
Hz 60
W 6200
L2 (red)
N (white)
G (green)
L1 (black)
L2 (red)
N (white)
G (green)
L1 (black)
cable from
power supply
Receptacle
NEMA 14-50R
ELECTRICAL GROUNDING
This oven is equipped with a four-prong plug for protection against shock hazard and
should be plugged directly into a properly grounded receptacle. A properly grounded and
horizontally-mounted NEMA 14-50P electrical outlet should be installed in the wall behind
the range at least 2" (51 mm) above the floor and not more than 8" (203 mm) from the
bottom left side (facing product).
Disconnect electrical power at the circuit breaker box or fuse box before
installing the appliance. Provide appropriate ground for the appliance.
Use copper conductors only. No attempt should be made to operate the
appliance during power failure.
WARNING
INSTALLATION
