6
INFLATION SYSTEM
The inflation system is composed of:
THE FOOT PUMP
a. connecting tip
b. hose end piece
c. hose base
d. outlet for inflation
a
b
c
d
THE STANDARD VALVES
(1) cap (2) valve insert (3) base
To activate the standard valves into INFLATION
position:
• Free the valve insert from its protection.
• Unscrew the valve cap.
• Screw the valve support onto its base (screw it
tight but without exaggeration, not to deteriorate
the screw thread) and check that the valve cap
stays accessible.
TO DEFLATE:
Unscrew the valve support from its base
1
2
3
THE VALVES « EASY – PUSH ».
To change the position: Inflation position Deflation position
Push / Push
diaphragm closed, the inner
button springs upwards
diaphragm open, the inner
button goes down
