Remove Debris from Engine
WARNING
Toavoidseriousinjury,makesurethatthecleanerisdisconnectedfromthehoseandthesuctionpumpused
forthecleaneristurnedoffpriortostartingthisoperation.
1. Pushthelatchreleasebuttononthetopofthecleaner.
2. Rotatethetopassemblybackuntilitclicksintoanupwardposition.
3. Lookintoengineandremovedebristhatispresent.
4. Ifneeded,slowlypushenginepaddlesforwardand/orbackwardstomovestuckdebristoanaccessible
positionthenremoveit.Whenmovingtheenginepaddles,makesurethecleanertracksareallowedtomove
freelyastheywillturnastheenginepaddlesrotate.
5. Closeenginetopandensurethelatchclicksinplace.
Latch Release
Button
