Cleaner Vacuum Modes
TheBaracudaMX8PoolCleanerisdesignedwithtwo(2)vacuumoptions:
1. Small debris cleaning mode:Forvacuumingsmallerandheavydebris,suchas,sand,siltandsmall
stones.Thepoolcleanerissentfromthefactoryinthismode.
2. Large debris cleaning mode:Forvacuuminglargedebris,suchas,leaves.
WARNING
Toavoidseriousinjury,makesurethatthecleanerisdisconnectedfromthehoseandthesuctionpumpused
forthecleaneristurnedoffpriortostartingthisoperation.
To convert the pool cleaner to the large debris cleaning mode:
1. Grasptheyellowinletadapterandinsertafingerintotheadapterhole,asshownbelow.
2. Liftuptherearedgeoftheinletadapterandthenpullitoutofthevacuuminlet.
Inlet adaptor
Front of cleaner
Front edge
Rear edge
Cleaner with the
inlet removed
To convert the cleaner back to the small debris cleaning mode (original from factory):
1. Placetheyellowinletadapterinthevacuuminletofthepoolcleaner.Pushdownontheyellowinletadapter
untilboththefrontandrearedgesclickintoplace.
