POSITION OF ACCESSORIES
VI -1 LOCATION OF CONSOLE T4
Some consoles may be fitted in your boat; we recommend putting them in the locations
given below to optimise use of your boat and use the below-deck cable feedthroughs.
In addition, some areas, particularly above the tank, require extra precautions when
installing the tank (see diagram).
The positioning measurements are given from the rear chest.
JOCKEY 2-seat CONSOLE
Ø
A*
C
B
* the JOCKEY console may be moved forward up to the feedthrough hole
ACCES CONSOLE
Ø
D
A
B
C
Tank
access
hatch
Tank
access
hatch
