8
2.2 Aachment to the base
2.3 I Electricity supply connecon
In order to avoid any risk of electrocuon, re or serious injury, please follow the instrucons
below:
• Use of an electrical extension is prohibited when connecng the control box.
• Make sure that the socket can be easily accessed at all mes and is protected from rain or
splashes.
• The control box is impervious to spray but must not be immersed in water or any other liquid.
It must not be installed in a oodable area; keep it at least 3.5 metres away from the edge of
the pool and avoid exposing it to direct sunlight.
• Place the control box near the socket.
• Connect the oang cable into the control box (see gure ).
• Push the connector in unl you hear 2 clicks (see gure ). Make sure the connector is suciently pushed into place.
If it is not, repeat the operaon.
• Connect the power cord (see gure ). Only connect the control box to a power outlet protected by a 30 mA
maximum residual current device (if in doubt contact a qualied technician).
• To disconnect the oang cable from the control box, pinch the 2 clips at the end of the connector and pull at the
same me (see gure
).
CLICK
CLICK
