Zoeller BASEMENT SENTRY II User Manual

5
© Copyright 2013 Zoeller Co. All rights reserved.
ASSEMBLY WITH SUBMERSIBLE PUMP
FIGURE 1
ASSEMBLY WITH COLUMN PUMP
FIGURE 2
SK1222 SK1223
*The 8 3/8" Dimension can be altered to accommodate small basins with min. depth of 24".
*
"ON" LEVEL
PRIMARY PUMP
END OF PIPE
END OF PIPE
7 3/16" PIPE REMOVED
OUTLET PUMP PRIMARY
BATTERY BOX
8 3/8"
5 3/8"
1/8" WEEP HOLE
1/8" WEEP HOLE
BATTERY BOX
PRIMARY PUMP "ON" LEVEL
7 1/2"
5 3/8"
*
8 3/8"
END OF PIPE
END OF PIPE
7 3/16" PIPE REMOVED
PRIMARY PUMP OUTLET
