Zoeller QWIK JON 100 User Manual

10
© Copyright 2013 Zoeller Co. All rights reserved.
IN A TEE OR Y IN PLASTIC PIPE.
HUB CONNECTOR OR WELD
SANITARY TEE OR Y WITH NO
SEWAGE DRAIN LINE. USE
DISCHARGE TO 3" OR LARGER
PLASTIC.
WELDED IN
Y OR TEE
3" (4") x2"
DISCHARGE
UNION BY OTHERS
CORD SEAL
BACKFLOW DEVICE
3" (4") x2"
CAST IRON
CONNECTORS
W/NO HUB
Y OR TEE
FLOOR JOIST
REQUIRED ON DISCHARGE PIPE.
TO ROOF VENT
ACCORDING TO LOCAL CODES.
PIPING MUST BE INSTALLED
NOTE: ALL VENTS AND DISCHARGE
115V GROUND FAULT CIRCUIT INTERRUPTER (GFCI).
DISCHARGE
IF UNIT IS 230V THEN INSTALL GFCI
5' VERTICAL ELEVATION
6" APPX.
OR
FLOOR
VENT
TO ROOF VENT
6" APPX.
VENT
SHUT-OFF VALVE
BY OTHERS
PROTECTION IN THE ELECTRICAL PANEL.
SK1586
TYPICAL PIPING CONFIGURATIONS
NOTE: All installations must comply with all ap-
plicable Electrical and Plumbing Codes, including,
but not limited, to National Electrical Code: Local:
Regional and/or State Plumbing Codes, etc.
