General Information 20X Bar-tacking and Button Sewing Machine(LCD N)
45
1 General Information
1.1 Technical Parameters of 20X
No.
20X
1
Purpose
Bartacking / Button Lockstitch
2
Sewing Area
X(lateral) direction 40mm × Y(longitudinal) direction 30mm
3
Max. Sewing Speed
Doubling & Tacking：3200rpm
Button Sewing：2700rpm
4
Stitch Length
0.1mm – 10.0mm (adjustable by 0.1mm)
5
Cloth Feed
Intermittent Feed(2-axis drive by pulse motor)
6
Needle Bar Stroke
41.2mm
7
Needle
DP ×5 #14 (DP×5 #11(F,M), (DP×17#21 thick cloth))
8
Type of Lifting Presser Foot
Driven by pulse motor
9
Height of Presser Foot
14mm (Standard), Max. 17mm
10
Total Number of Standard Patterns
100
11
Wiper Type
To work together with Presser Foot driven by Pulse Motor
12
Thread Catching Device
Standard : 0
13
Needle Thread Tension
Electrical Thread Tension Release
14
Shuttle
Standard Semi-rotary Hook or Semi-rotary Double Hook
15
Lubricating Method
Rotary Part: Lubricate with minimum amount
16
Lubricating Oil(Liquid)
Ordinary Sewing Machine Lubricating Oil (Liquid)
17
Grease
Ordinary Sewing Machine Grease
18
Data Memory
Flash Memory
19
Scaling Facility
20%~200%(by 1%) in X direction and Y direction respectively
20
Scaling Method
By increasing/decreasing the stitch length
21
Max. Sewing Speed Limitation
400-3200rpm (by 100rpm)
22
Pattern Selection
Specifying Pattern No. Type (1-200)
23
Bobbin Thread Counter
Up/Down Type (0 – 999999)
24
Sewing Machine Motor
550W Compact AC Servomotor (Direct Drive)
25
Dimensions
208mm×106mm×64mm
26
Weight
1.4Kg
27
Rated Power
770W
28
Operation Temperature Range
0℃ - 45℃
29
OperationHumidityRange
35% - 85% （No Dew Condensation）
30
Line Voltage
AC 220V ± 10%; 50-60Hz
 Please reduce the max. sewing speed in accordance with the sewing conditions.
 Effective standard for product:QCYXDK0004—2016 “Computerized Control System for Industrial Sewing
Machine”
TYPE
ITEM
