■WARNING - THIS APPLIANCE MUST BE EARTHED
GREEN AND YELLOW
13 AMP FUSE
BROWN or REDBLUE or BLACK
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow: Earth Brown or Red: Live Blue or Black: Neutral
If the colours of the wires in the mains lead of this appliance do not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows.
The wide coloured green-and-yellow must be connected to the terminal in the plug which is marked with the letter E or
by the earth symbol or coloured green or green-and-yellow. The wire coloured blue must be connected to the terminal
which is marked with the letter N or coloured BLACK.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured RED.
This appliance must be protected by a 13A fuse if a 13A (BS1363) plug is used or, if any other type of plug is used, by
a 10A fuse either in the plug or adaptor or at the distribution board.
