Cellular Radio
Huawei MU609
Antenna Specifications
Main and Diversity Antenna
Specification Requirement Comment
Frequencies
supported
850 Mhz Band (824-894 MHz)
900 Mhz Band (880-960 MHz)
1800 Mhz Band (1710-1879 MHz)
1900 Mhz Band (1850-1990 MHz)
2100 MHz Band (1920 – 1980 and
2110 - 2170 MHz)
These frequencies cover all possible
frequencies supported by the modem. If
you are sure you are not using certain
frequencies than you may omit them when
selecting your antenna.
Gain ≤ 2.5 dBi
Polarization Vertical
Radiation
Pattern
Omni-directional
Impedance 50 Ω
VSWR ≤ 2:1
Antenna
Efficiency
≥ 50% Can be ≥ 40% for less than 960 MHZ,
≥ 50% for greater than 1710 MHz
GPS Antenna
Specification Requirement
Frequencies supported 1574.42 MHz–1576.42 MHz
Polarization RHCP (Right-Hand Circular Polarization)
Radiation Pattern Directional, point to the upper hemisphere
Impedance 50 Ω
VSWR ≤ 1.5:1
Antenna Efficiency
≥ 50% for both the efficiency and the upper hemisphere efficiency
52
