30 ADSL X6 Quick Start
The following table describes the back panel.
Port Description
PWR
Port to connect the unit to the X6’s power cube.
RESET
Button to reset the modem to its system default settings
(necessary if communication link is lost). To reset, you must
insert a paper clip and press the button quickly three times.
LAN 1
LAN 2
LAN 3
LAN 4
LAN ports that can connect the unit to an access point, a
network hub, or the Ethernet port of a computer. The X6 has
four LAN
ports.
Each port has a small yellow and a green light above it. The
yellow light turns on when data is being received at 100
megabits per second and off when it is receiving at 10
megabits per second. The green light blinks when there is
activity on that particular LAN line.
ADSL
Jack to connect the modem to the ADSL telephone wall jack.
