Zoom H1 Operating

Operating the Zoom H1 Recorder for Message Banking cont./…
4/5
4. Moving to the Previous/Next Recorded Message
When in play or pause mode, to move to the previous/next recorded message:
Press and release the tt Back arrows button on
the right side of the Zoom H1 to move to the
previous message.
or
Press and release the uu Forward arrows button
on the right side of the Zoom H1 to move to the
next message.
The current message recording number will be shown at
the top of the screen.
Repeatedly press the Back arrows or Forward arrows
button until you reach the recording number that you are
looking for.
5. Adjusting the Play Volume
For listening back to recorded messages, you can set the volume from 0 -100.
To change the playback volume:
Press the or Volume button on the left
side of the Zoom H1.
The screen will display the current volume
setting number.
If you find it hard to hear the playback:
o The play speaker is on the bottom of the
Zoom H1. Hold this part to your ear to get
the clearest play sound.
o Alternatively, using headphones helps.
Plug headphones with a jack connector
into the port on the top left
side of the Zoom H1.

Zoom H1 Specifications

General

Recording Format	WAV, MP3
Max Sound Pressure Level	120 dB SPL
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Sample Rate	44.1 kHz, 48 kHz, 96 kHz
Connectivity	USB 2.0
Input	3.5mm stereo mini-jack
Output	3.5mm stereo mini-jack
Power Supply	1x AA battery or USB power
Weight	60 g (without battery)
Bit Depth	16-bit/24-bit
Recording Media	microSD/microSDHC card
Frequency Response	20 Hz to 20 kHz
Dimensions	44 mm (W) x 136 mm (D) x 31 mm (H)
