(2) REVERB TIME/ADJUST control
The function of this control differs, depending on
which effect bank is currently selected with the
BANK switch.
(1) MIX control
Adjusts the mixing balance between the original sound and the effect sound.
• When using the insert type connection pattern
• When using the send/return type
connection pattern
• REVERB bank selected
Use the MIX control to adjust the mixing
balance between original sound (DRY) and
effect sound (WET).
For effects such as compressor/limiter or
microphone simulator where the output is
the processed original sound, turn the MIX
control fully to WET.
The MIX control should be turned fully
to WET, so that only the effect sound
is output. The mixing balance between
original sound and effect sound
should be adjusted at the mixer or
multi-track recorder.
Effect sound
Original sound
Only effect
sound is output
11 reverb character
settings
Unprocessed sound
(original sound)
Processed
sound
The control adjusts the reverb duration.
• EFFECTS or MIX&SFX selected
The control adjusts a major parameter of the
currently selected effect.
The control adjusts a major parameter of the
currently selected effect.
(3) CHARACTER/VARIATION selector
The function of this selector differs, depending
on which effect bank is currently selected with
the BANK switch.
For information on which parameters can be
adjusted for each effect, see pages 8 - 15.
For information on which parameters can be
adjusted for each effect, see pages 8 - 15.
• REVERB bank selected
The selector can be used to choose one of 11
reverb sound characteristics (settings with
different tone and intensity).
• EFFECTS or MIX&SFX selected
Short reverb Long reverb
