8
Recording
Connecting Instruments
Connecting Instruments
Bass guitar
(TRS cables)
(mono phone cable)
Keyboard
Guitar
Connect instruments to INPUTS 1/2 using TRS/mono phone cables.
<Front>
Using the Hi-Z Function
• When connecting a passive guitar or bass guitar to
an INPUT, press its so that it lights.
• When connecting a keyboard or other instrument to
an INPUT, press its so that it becomes unlit.
To Next Page
