Zoomo Zero - PEDALS; FITTING PEDALS

A. FITTING PEDALS
To install your pedals, follow these steps:
1. Put a small amount of mounting
grease (you can nd this at your
local bike retailer) on the thread of
each pedal.
2. Tighten the right pedal (marked «R»
on the pedal, see Figure 13) in a
clockwise direction on the crank
on the drive side.
3. Tighten the left pedal (marked «L»
on the pedal, see Figure 13) in an
anti-clockwise direction on the
crank on the left side.
4. The recommended torque is 30 Nm.
PEDALS
Figure 13. Pedal threads. Make sure
you rotate the correct direction
09
