18
LUGGAGE RACK AND MUDGUARDS
A. MUDGUARD CLEARANCE
Zoomo models are equipped with
aluminium mudguards ensuring a high level
of stiness. Always respect a minimum
gap of 6 mm at all points between the
tyre and the mud guard.
(see Figure 34)
This should be checked regularly and at
each time that you change the tires on
your bike. Keep to the size of tire
equipped on your bike at sale in order to
keep the right size gap. If the gap is less
than 6 mm contact your retailer so that
he/she can adjust as necessary.
Regularly check that the xation points
on your mudguard are tight.
(see Table 1 Recommended Torque Values)
6 mm
minimum
Figure 33. Mudguard /
Fender Clearance.
B. LUGGAGE RACK & PAYLOAD
! WARNING Do not exceed the luggage
total loading of 27kg. The total payload of
the bike should not exceed 200kg.
(rider + cargo)
! ATTENTION Ne dépassez pas la charge
totale des chargement de 27 kg. La
charge utile totale du vélo ne doit pas
dépasser 200 kg (cycliste + chargement).
We have equipped Zoomo bikes with
specic luggage racks. These luggage
racks are designed for a maximum load of
27 Kg. This is in line with ISO11243
EPAC/CE.
Never attempt to modify your luggage
racks, its xation points, or to go over the
maximum load limit as this can damage
your bike and cause a fall and injury.
Always use the supplied luggage strap to
secure any items.
When your luggage rack is loaded, the
behavior of your bike will be aected.
Weight is added to the rear of the bike,
and this will modify the handling and
braking of your bike. In order to keep a
good level of balance on the bike, divide
the load as evenly as possible on both
sides of the bike.
The luggage rack is designed to be
equipped with a trailer hitch for towing a
EPAC compliant trailer (see C below).
