zortrax M200 Quick Start Guide

1. When the printing process is finished, turn off the printer
using the power switch. Disconnect cables from the Build
Platform.
2. Remove Build Platform.
3. Remove printed model using spatula. Please use gloves,
also using safety glasses is recommended. Place the Build
Platform back in the printer and connect the connectors.
WARNING! Before removing the platform, detach
connectors from the Build Platform.
14
PRINTING

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
