Zotac ZBOX CI331 NANO User Manual

ZOTAC ZBOX nano
6
Getting to know your ZOTAC ZBOX nano
Front view
1. Power button
The power button turns the mini-PC ON and OFF.
2. Power LED
The Power LED is always ON when power is on.
3. SATA status LED
The SATA LED blinks when data is being written onto or read from the SATA.
4. Wi-Fi status indicator
The Wi-Fi LED is always ON when data is being transfered over Wi-Fi.
5. Memory card reader
The built-in memory card reader reads SD/SDHC/SDXC cards used in devices such as digital
cameras, MP3 players, mobile phones and PDAs.
6. Headphone/Audio Out jack
The stereo headphone jack (3.5mm) is used to connect the system’s audio output signal to
amplied speakers or headphones.
7. Microphone input
The microphone input is designed to connect a microphone for video conferencing, voice
narrations or simple audio recordings.
8. USB 3.0 Type-C port
The USB 3.0 Type-C port supports the SuperSpeed USB 3.0 devices. Use the port for USB
3.0 devices for maximum performance with USB 3.0 compatible devices.
9. USB 3.0 port
The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards compatible
with USB 2.0/1.1 devices. Use the ports for USB 3.0 devices for maximum performance with
USB 3.0 compatible devices.
1
2 3 4
5
6 7
8
9

Zotac ZBOX CI331 NANO Specifications

General

Brand	Zotac
Model	ZBOX CI331 NANO
Category	Desktop
Language	English
