ZOTAC ZBOX
14
Installing M.2 SSD and Optane memory modules
There are two M.2 slots to support PCIe X4, SATA III SSD and Optance memory accordingly.
M.2 PCIe x4 SSD /
Optane memory slot
(22/42, 22/80, 22/110)
M.2 PCIe x4 /
SATAIII SSD slot
(22/42, 22/80)
This is example to install a M.2 PCIe x4 / SATA SSD module, similar steps for installing 2nd
PCIe x4 SSD or Optane memory module into another slot.
1. Remove the screw securing the hard disk bracket.
