02418V10 • 11.08.2016/DC • 1-17
Adjustments
1.10 Adjustments
1.10.1 Adjust thread tension
The thread tension will be adjusted with the knurled ring of the rear and front
tension regulator
Clockwise rotation Thread tension is increased
Counter clockwise rotation Thread tension is decreased
The thread tension has to adjusted with both knurled rings, so
that the bobbins will be fi lled not to tight and that after thread
cutting the thread breakage sensor not interrupted the winding
process.
The correct thread tension at the bobbin case is shown in the fi gures below:
