1-18 • 02418V10 • 11.08.2016/DC
Adjustments
1.10.2 Thread breakage sensor
The thread breackage sensor is used for monitoring and interruption the winding
process at thread breakage or an empty yarn cone. By reduction of thread tension
through occasions outlined above the thread breakage sensor gets loose, moves up
and interrupt the winding process.
1.10.3 Retracting bowl
The retracting bow hold the thread during the winding process in a position,
which warranted, that the bobbin thread moves preferably vertical from above
into the bobbin support.
After thread cutting the bobbin thread is slightly retired at the cutter from the
retracting bow, that means, for the next winding process the lenght of sagging
bobbin thread will be slighly reduced, so that no overlaying thread (thread
beginning) is formed when winding the next bobbin.
Rear tension regulator
Thread breakage sensor
Front tension regulator
Retracting bowl
