02418V10 • 11.08.2016/DC • 1-9
Assembly
• Release the white knurled screw.
• Rotate the thread bow evincible
showing in a horizontal position.
• Slide the wire eye forward into the
mounting hole until it is placed central
over the yarn cone bracket.
• Tighten the knurled screw.
• Plug the coupling device from the
yarn guide to the winder connector.
