Description:
In this example, the ADSL Router acts as a bridge which bridging PC IP address from LAN to WAN. PC IP address
can be a static public address that is pre-assigned by ISP or a dynamic public address that is assigned by ISP DHCP
server, or can be got from PPPoE software.
Therefore, it does not require a public IP address. It only has a default private IP address (192.168.100.100) for
management purpose.
Configuration:
1. Choose a client PC and set the IP as 192.168.100.x (x is between 2 and 254) and the gateway as
192.168.100.100.
2. Start up your browser and type 192.168.100.100 as the address to enter the web-based manager.
3. Go to Configuration >WAN Configuration > Create a New PVC and select the Data Mode –RFC1483
Bridged. Then click Next button.
4. Enter the VPI/VCI values provided by your ISP and select the encapsulation type as LLC/SNAP or VC MUX.
Then click Apply.
5. Save the configuration from System >Save Configuration and System >Restart to restart your router for
initiating these settings.
