ZXHN H108L User Manua
l
10
If you don’t want Internet services and telephone voice services simultaneously,
please just connect the LINE port of the Gateway with the RJ-11 port (the
phone jack) on the wall using a telephone cord. In this case, the splitter is not
necessary.
Connection procedures
1 Power off the equipment before all the other devices are connected.
2 Connect the network cables: Insert the RJ-45 Ethernet cable connector into
the Ethernet interface of the ZXHN H108L, and connect its other terminal to
the Ethernet adapter of the customer computers or ports of other network
devices.
3 Connect the splitter
The splitter has three interfaces, which are described as follows:
z LINE: Connect the user telephone cable (RJ11 interface).
z MODEM (or ADSL): Connect the DSL interface of the ZXHN H108L.
z PHONE (or TEL): Connect the phone sets.
The installation process is as follows: Connect the LINE interface of the ZXHN
H108L to the MODEM(or ADSL) interface of the splitter using the RJ-11
telephone cable, connect the phone set lines to the PHONE(or TEL) interface
of the splitter, and then connect the user telephone cable port to the LINE
interface of the splitter.
4 Connect the power
Connect one terminal of the power adapter to the POWER interface of the
ZXHN H108L, and the other terminal to the socket on the wall, and then switch
on the power of the ZXHN H108L equipment.
Checking all connection cables
Check all connection cables following the below procedure.
1 Check the ADSL cable connection
