Zte ZXR10 2800-4 - 2.2 Power Supply

ZXR10ZSRV2HardwareDescription
2.2PowerSupply
TheZXR10ZSRV2seriesrouterssupport100Vto240V,50Hzto60HzACpower
supplyand-72Vto-38VDCpowersupply.TheZXR103800-8supportsACandDC
mixedpowersuppliesoperatingin1+1redundancymode,andthepowersupplymodules
arehotswappable.
Apowersupplymoduleprovidesthefollowingfunctions:
lInput/outputover/undervoltagealarmandprotection.
lOutputovercurrentalarmandprotection.
lTemperaturealarmandoverheatingprotection.
Caution!
Pleasedisconnectallpowersupplybeforeservicing.
2.2.1ACPowerSupplyModule
Panel
ForthefrontviewoftheACpowersupplymoduleoftheZXR103800-8,seeFigure2-4.
Figure2-4PaneloftheACPowerSupplyModule
Indicators
ForadescriptionoftheZXR103800-8ACpowersupplyindicators,refertoT able2-3.
Table2-3IndicatorDescriptionsfortheZXR103800-8ACPowerSupplyModule
IndicatorNumberColorDescription
RUN1GreenIndicatesthatthepowersupplymodule
operatesproperly.
ALM1RedIndicatesthatthepowersupplymodulehas
analarm.
