ZWO ASI2600MC DUO User Manual

3.2 Specification
Main Sensor
Guide Sensor
Sensor
SONY IMX571
SC2210_BW
Color & Mono
Color
Mono
Sensor format
APS-C
Type 1/1.8
Diagonal
28.3mm
8.81mm
Resolution
26MP 6248x4176
2.07MP 1920x1080
Pixel size
3.76μm
4μm
Sensor size
23.5mmx15.7mm
7.68mmx4.32mm
Max FPS at full resolution
15fps
16.9fps
Shutter
Rolling shutter
Rolling shutter
Exp range
32μs-2000s
32μs~10s
Readout noise
0.9-4.2e (1.3e@10db gain)
0.6-3.2e (1.97e@10.6db gain)
QE peak
80%
92% at 500nm
Full depth
73Ke*
8.78Ke
ADC
16bit
12bit
DDR3 buffer
512MB
\
USB port
USB-B 3.0
\
Adapter
M54x0.75
\
Protective window
UV/IR CUT
Camera diameter
90mm
Camera weight
715g
Back focus distance
17.5mm
Cooling
Two-stage TEC cooling
\
Delta T
30°~35°@30℃ ambient
temperature
\
Cooling power load
12V, peak current 3A
\
Supported OS
Windows, Linux & Mac OSX
Max power consumption
12V power: 27.48W
USB power: 0.46W
*Note: The default full well capacity of ASI2600MC Duo is 50Ke. But at the gain value of -25, it will be expended
to 73Ke.

ZWO ASI2600MC DUO Specifications

General

Brand	ZWO
Model	ASI2600MC DUO
Category	Digital Camera
Language	English
