INTRODUCTION
3
Model Descriptions
Model Description
7200 Base optical profiler with a high resolution camera, manually
interchangeable single field zoom lens, filter tray, aperture stop, and a turret
compatible closed loop transducer.
7300 All the features of Model 7200 plus- an aperture stop, an enhanced
illuminator, a higher speed camera, and an automatic three-position field
zoom lens turret.
NewView Options
Option Description
Field
Zoom
Lens
High-quality discrete field zoom lenses provide superior image
magnification and are available in the following powers:
0.5X, 0.75X, 1.0X, 1.5X, and 2.0X.
NewView 7200 accepts a single field zoom lens; the lens can be
manually interchanged. NewView 7300 accepts up to three field
zoom lenses automatically selected via software.
Objective Interferometric infinite conjugate objectives provide sharp images of the
part under test. ZYGO offers standard and long working distance
objectives in magnifications ranging from 1X to 100X.
Objective
Mounting
● Single objective dovetail.
● Manual 6-position turret.
● Motorized 6-position turret.
Camera ● 640 x 480 (VGA) high-resolution camera (standard).
● 992 x 992 (1K) ultra-high resolution camera (option for NewView 7300).
Stages
● 1-axis stage; Motorized Z (focus), Manual Tip/Tilt and X/Y.
● 3-axis stage; Motorized Z (focus) and X/Y, Manual Tip/Tilt.
● 5-axis stage; Motorized Z (focus), Tip/Tilt, and X/Y.
● 5-axis stage; Motorized Z (focus), Tip/Tilt, and X/Theta.
● 5-axis stage; Motorized Z (focus), Tip/Tilt, and Y/Theta.
The number of stage axes indicates the total number of
motorized axes in the configuration.
The motorized Z stage and motorized X/Y stages are also
available in a closed loop configuration.
Accessories are described in the NewView 7000 Accessory Guide,
OMP-0543.
