End of dialling (empty=off) – a selectable DTMF code for DTMF dialling end in the
event of a DISA incoming call. The default value is '#'.
VoIP parameters
VoIP functions
Day of deleting statistics on VoIP (every month) – the day of automatic deletion
of call statistics on the VoIP interface. None = no deletion.
SIP protocol settings
Use CLIP from INVITE field – the CLIP as set in the or field will beContact From
used for routing calls into GSM/UMTS networks.
Send 180 ringing instead of 183 session progress.
Send 200 OK instead of 180/183.
Send 200 OK and BYE when rejected from GSM.
Send 200 OK on REGISTER request – virtual registration of the device in 2N
®
(necessary for registration–requiring equipment). VoiceBlue Next
Replace CLIP from GSM with Caller ID.
Deny DTMF according to RFC2833.
Forward DTMF for ME (Mobility Extension).
SIP registration
Registration expires [s] – the timeout after which the 2N VoiceBlue Next
®
registration data expire at the SIP Proxy.
Reattempt registration [s] – time interval for re-sending the request.
Registration domain (realm).
Caller ID.
Username – registration data for the SIP Proxy.
Password – registration data for the SIP Proxy.
Voice parameters
First RTP port (even: 1024 – 65524) – number of the first RTP port. The number
must be even as recommended.
Last RTP port (even: first RTP+10 – 65534) – number of the last RTP port. The
number must be even as recommended. The recommended minimum range of
RTP ports should be 10.
Codec settings
detailed codec settings (G.711a/u, or G.729).
Codec priority
preferential speech codec setting:
Priority 1
Priority 2
Priority 3
