4.4 CDR
For the current CDRs see the section or useGateway–>Gateway control–>CDR file
the AT&C / AT&CR AT commands for Telnet sessions.
**Date Time Type Cause From/to Groups conn. durat. aoc-info gid CDN CGN
IMSI/SCID
Column 1: **
Column 2: call date and time
Column 3: call status
I–FD : failed incoming call
I–OK : successfully connected incoming call
O–FD : failed outgoing call
O–OK : successfully connected outgoing call
Column 4: release cause sent to ISDN
Column 5: used channel number / used GSM module
Column 6: used GSM group (C=CallBack)
Column 7: connection time
Column 8: call duration mmm:ss (max. 255:59), or error cause for unconnected
call
9:Column call cost (to be implemented in higher firmware versions) / gateway
ID (optional)
10:Column called party number (CDN)
Column 11: calling party number (CGN)
Column 12: SIM card slot number / SIM card IMSI or SCID
