Predator Installation Manual Ver 2.9 Page 16
© 360 Vision Technology Ltd.
MAINS FUSE
PRED-PSU-SM-WA-A
MAINS FUSE 3 = 2AF
OUTPUT FUSE
PRED-PSU-SM-WA-A
FUSE 1 = 6.3AT
FUSE 2 = 1AT
FUSE 4 = 1AT
MAINS input
100 - 240Vac
Io Vo
Adj Adj
Model Number: PRED-PSU-SM-WA-A
Serial Number: yymmndd-xxxx
Input Voltage:100-240VAC 50/60Hz
Input current 2.1A
Output Voltage: 30V DC
Output Current: 6.2A
Coax Core
Coax Screen
RED
ORANGE
RS485 D+
RS485 D-
Use pre-made cable PRED-3M,
PRED-10m, PRED-25m or
PRED-40m to connect to
Predator.
NOTE - All wires in
composite cable must
be connected.
255 x 180 x 100mm
Enclosure Dimensions
Coax Core (TC)
Coax Screen (TC)
24Vac(+)PINK
24Vac(-)GREEN
24Vac(+)GREY
24Vac(-)WHITE
24Vac(+)BROWN
24Vac(-)BLACK
To Analogue
Controller
To Next Page
