9 Predator OSD
OSD (On Screen Display) is accessed by dening/programming preset 6 or 95.
• Use the joystick up, down, left and right to navigate the menu. • Use the joystick zoom in to highlight/select an option. • Use joystick left and right to increment/decrement numbers.
Tour 001 item ...
PreDelSpd
Old................. New................ 0 1 2 3 4 5 6 7 8 9 Accept Item Accept Final Item Clear item Return Exit
DEFINE MIMIC
Mimic Number 001 Start Recording Return Exit
DEFINE PRESET
Preset Number ... 0 1 2 3 4 5 6 7 8 9 Accept Entry Clear Entry Return Exit
DEFINE HOME FUNCTION
Action Tour Number 001 Delay Minutes 010 Delay Seconds 000 Accept Changes Return
PRIVACY ZONE MENU
Dene Privacy Zone Seek Privacy Zone Remove Privacy Zone Return Exit
SERVICING
Power Reset Dome Factory Reset Dome Predator Software Version Return Exit
Dene Tour Dene Mimic Dene Preset Dene Home Function Return
Dene Tour Dene Mimic Dene Preset Dene Home Function Settings Menu Text Field Menu Servicing Privacy Zone Menu Preset Mapping Return
SEEK PRESET
Preset Number ... 0 1 2 3 4 5 6 7 8 9 Accept Entry Clear Entry Return Exit
START TOUR
Tour Number 001 Start Tour Return Exit
START MIMIC
Mimic Number 001 Start Mimic Return Exit
DOME SETTINGS MENU
Pin Number ... 0 1 2 3 4 5 6 7 8 9 Accept Entry Clear Entry Return Exit
DOME MENU
Seek Preset Start Tour Start Mimic Dome Settings Menu Exit
9.1 PIN Number Operators PIN: 360 or 426 or 180 Controllers PIN: 1379 or 9731 Engineers PIN: 5498
TEXT FIELD EDIT
---------------------------------------
0123456789 :ABCDEFG HIJKLMNOPQRSTUVWXYZ
X Position: 000 Y Position: 000 TEXT Display: OFF Accept Entry Clear Entry Return
PRESET MAPPING
Presets 01 to 07 Presets 08 to 14 Presets 15 to 21 Return
General Settings Pelco Settings Night1 Settings Night2 Settings Lamps Settings Shutter Settings Thermal Settings Return
WARNING
All Stored Data Will Be Permanently Erased Continue Return Exit
DEFINE PRIVACY ZONE
Privacy Zone ... 0 1 2 3 4 5 6 7 8 9 Accept Entry Clear Entry Return Exit
SEEK PRIVACY ZONE
Privacy Zone ... 0 1 2 3 4 5 6 7 8 9 Accept Entry Clear Entry Return Exit
REMOVE PRIVACY ZONE
Privacy Zone ... 0 1 2 3 4 5 6 7 8 9 Accept Entry Clear Entry Return Exit
FINISH MIMIC BY
DEFINING ANY PRESET
No. ACTION SEEK 01 a) none NO 02 b) none NO 03 c) none NO 04 d) none NO 05 e) none NO 06 f) none NO 07 g) none NO Accept Changes Return
Controller level
Engineer level
Digital Zoom ON White Balance OUTDOOR Line Lock ON Line Phase +056 Video Gain 002 Video Lift 000 Wide Dynamic OFF Sunshield OFF Accept Changes Return
Auto Flip SEMI Proportional OFF Freeze Presets ON Zoom Speed 007 OSD Preset Six YES Upright Mount ON Aperture(day) 010 Attack Detect ON Accept Changes Return
Wiper Rest (s) 000 Wiper ON time (h) 000 Wiper ON time (m) 000 Wiper ON time (s) 000 Wiper Permanent OFF FV Text Control OFF AF AI When PTZ ON Noise Reduct (day) 0 Accept Changes Return
White Lamps YES White When Alarm ON White Timeout ON White Timeout (m) 001 Auto Dimming YES FV White Lights a)YES Power on Park YES White Exclusion YES Accept Changes Return
Low Light Angle 000 Low Light Value 100% Accept Changes Return
Preset Dene ON Pelco D Response NO Ultrak Cmd T/out ON Arms CANTED Accept Changes Return
Aux1 a) auto focus Aux2 b) digital zoom Aux3 c) auto iris Aux4 d) ir Aux5 e) wiper Aux6 f) washer Aux7 g) osd Aux8 h) backlight Accept Changes Return
Col/Mono Change: Dark Mono On 020 Mono O󰀨 013 1=day 7=dusk 20=dark Brightness Bright Bright Control Preset Accept Changes Return
Illumination IR Lamp Intensity 100% Camera Mono External Lighting Yes Aperture 3 Noise Reduction 0 Low Light Focus ON Night Presets OFF Accept Changes Return
Lamps1 Lamps2 Return
Fast Shutter OFF Fast Shutter Speed g:1/1000 Slow Shutter 1/3 sec Accept Changes Return
Gain mode a: Automatic Gain Control Mode a: Histogram Intensity Transform a: White Hot Dual Addressing OFF Accept Changes Return
General1 Settings General2 Settings General3 Settings General4 Settings Return
Thermal
Lamps
Shutter
Night 2
Night 1
Pelco
General
General 1 General 2 General 3 General 4 Lamps 1 Lamps 2
