Predator
Features
All Predator units have the following functions.
Video Output 1V p to p, 75Ω
Scanning PAL or NTSC
Focus/Iris Auto/Manual
Presets 360
Tours 16 (max 90 presets per tour)
Learned Patrols 4 mimic tours (up to 30 minutes duration each)
Privacy Zones Up to 32
Variable pan speed/coverage 0.1 ~ 120°/sec, 360° continuous rotation, absolute positioning.
Variable tilt speed/coverage 0.1 ~ 120°/sec, 180° rotation, absolute positioning.
Auto Homing Preset, Tour or Mimic.
Col/Mono Changeover 4 levels ( 3 xed preset, 1 user dened)
Operating temperature -40°C ~ 60°C with optional heater
Power 24Vac/dc
Certication CE approval : IP68
16 PSU Enclosure
Material PC/ABS
Dimensions (PRED-PSU-SM enclosure) 255 x 180 x 100mm
Predator
Specication
18x 28x 44x
Colour/Mono Yes
Imager 1/4” type Super-HAD CCD II
Zoom - Optical, Digital 18x, 12x 44x,12x
Pixels 976(H) x 582(V)
28x, 12x
Horizontal View Angle 2.8°(T) ~ 48°(W) 2.1°(T) ~ 55.8°(W) 1.6°(T) ~ 68.8°(W)
Lens Size 4.1 ~ 73.8mm 3.06 ~ 134mm
Min Sensitivity - Colour 0.4 Lux 0.4 Lux 0.6 Lux
Min Sensitivity - Mono Int 0.01 Lux 0.01 Lux 0.01 Lux
Signal Noise Ratio >50dB
3.5 ~ 98mm
Lines Resolution 670
15 Camera Specication
