360 Vision PRED-3M - PMA Bracket Dimensions

Predator Installation Manual Ver 2.9 Page 8
© 360 Vision Technology Ltd.
Predator PMA Bracket
Please use the appropriate xings to suit the weight of the camera housing used.
Weight 1kg
MUST NOT BE REPRODUCED OR SHOWN TO
DO NOT SCALE
ALL DIMENSIONS IN MM
REMOVE ALL SHARP EDGES
SHEET:
D
C
B
A
D
C
B
A
4
3
2
1
4
3
2
1
A3
DESCRIPTION
SCALE:
PERMISSION OF THE AUTHOR.
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
C COPYRIGHT PROTECTED AND
THIS DRAWING AND ALL COPIES ARE
PART NUMBER:
0.125
9 OF 9
TOLERANCES:-
X = 0.5
X.X = 0.1
X.XX = 0.05
A3
3rd ANGLE PROJECTION
360 Vision Technology Ltd.
Unit 7, Seymour Court,
Manor Park, Runcorn, Cheshire,
WA7 1SY. United Kingdom.
www.360visiontechnology.com
125
OUTSIDE
DIAMETER
9 (x4) ON
101.6 (4 INCH) PCD
USE M8 BOLT FOR
FIXING TO POLE
60
M8 (x4) ON 101.6
(4 INCH) PCD.
FIX PREDATOR USING:
M8x30 HEX-HEAD BOLTS (x4)
- STAINLESS STEEL.
M8 SPRING LOCK WASHER (x4)
- STAINLESS STEEL.
73
M20x1.5P
M20x1.5P
73
M20x1.5P
8.0 (x4) ON 101.6
(4 INCH) PCD.
FIX PREDATOR USING:
M8x30 HEX-HEAD BOLTS (x4)
- STAINLESS STEEL.
M8 SPRING LOCK WASHER (x4)
- STAINLESS STEEL.
53.0
125
OUTSIDE
DIAMETER
M20x1.5P
10 (x4) ON
101.6 (4 INCH) PCD
USE M8 BOLT FOR
FIXING TO POLE
NAME:
M5350-A
PREDATOR ASSEMBLY
STAINLESS STEEL
ISS DATE REFERENCE
A 290216 FIRST ISSUE
290216
DATE :
K.CRAIK
RELEASED:
APPROVED:
ENGINEER:
-- MATERIAL: FINISH:
MOUNT PREDATOR
TO THIS FACE.
MOUNT POLE
TO THIS FACE.
MOUNT PREDATOR
TO THIS FACE.
MOUNT POLE
TO THIS FACE.
MATERIAL:
STAINLESS STEEL
MASS = 3.6 Kg
PMA = STAINLESS STEEL
SCALE 0.5
SCALE 0.5
PMA = ALUMINIUM
MATERIAL:
ALUMINIUM
MASS = 0.93Kg
SCALE 0.5
SCALE 0.5
