Installing the Linux System through an Ethernet Connection 29
Figure 5 Network diagram for an Ethernet installation through Eth1
Figure 6 Network diagram for Ethernet installation through the management
Ethernet port Eth2
Configuring the TFTP
Server
Complete the following configuration procedure on the TFTP server:
1 Ensure that there is network connectivity between the TFTP server and the
switch installed with the OSN|M module.
2 Enable TFTP on the TFTP server, and store the configuration file and the
installation files listed in Table 8 on the TFTP server. (These files are
Switch with OAP
TFTP Server
Controller
GE
1
/
0
/
2
on switch
GE
1
/
1
/
2
Eth
1
Console
on OSN|M
Internal connection
between the OSN|M and the switch
IP network
DHCP Server
Switch with OSN|M
TFTP Server
Controller
Management
Ethernet port
(
Eth
2
)
on OSN|M
Console
on OSN|M
IP network
DHCP Server
