Upgrading from the Boot ROM Menu 65
Example TFTP Upgrade Procedure
BOOT MENU
1. Download application file to flash
2. Select application file to boot
3. Display all files in flash
4. Delete file from flash
5. Modify bootrom password
6. Enter bootrom upgrade menu
7. Skip current configuration file
8. Set bootrom password recovery
9. Set switch startup mode
0. Reboot
Enter your choice(0-9): 1
1. Set TFTP protocol parameter
2. Set FTP protocol parameter
3. Set XMODEM protocol parameter
0. Return to boot menu
Enter your choice(0-3): 1
Load File name :all_flash.app s3q05_01_00s168.app
Switch IP address :192.168.0.1 158.101.28.223
Server IP address :192.168.0.244 158.101.28.100
Are you sure you want to download this file to flash? (Y/N) Y
Attached TCP/IP interface to netdrv0.
Attaching network interface lo0... done.
Loading...............................................done
Free flash Space: 9920512 bytes
Writing flash.........................................done!
Please input the file attribute (main/backup/none):main
The attribute of s3q05_01_00s56.app is changed from main to none!
done!
The Boot Menu displays again.
Note: s3q05_01_00s56.app was the existing application file. The application file
s3q05_01_00s168.app will now be used when you reboot the switch using the
Main application. If you choose to reboot using the backup application, this file is
used when the main file is unavailable. If you choose None, the file is added to the
filesystem. You can change the attributes again using the procedure in XREF.
Upgrading the Software
from the Boot Menu
using FTP
To upgrade software to your Switch using FTP, perform the following steps:
1 From the Boot Menu, select option 1 Download application file to flash) to display
the following:
1. Set TFTP protocol parameter
2. Set FTP protocol parameter
3. Set XMODEM protocol parameter
0. Return to boot menu
