Step 2. Open Interlock guard
Step 3. Take out the granulate collector
Step 4. Push the shredder compartment latch and tilt the shredder
compartment open (as explained in 3.4.2).
Step 5. Reach for the two plunger knobs attached to the Filter screen and
pull them toward each other [1]. The Filter screen can now be rotated
down [2] and pulled out of the machine [2 & 3] and release the two
plunger knobs.
Step 6. To mount the Filter screen back in, simply do step 5 reversed.
Now that the machine is still opened, two small shafts on the sides are
visible in the back of the granulator shaft. Aim the two half slots on the
