3.4.6. REPLACING THE GRANULATOR KNIVES
WARNING
Always wear cutting proof hand protection when working with the
granulator knives.
Step 1. The rotating granulator knives are positioned by shoulder screws.
Apply Loctite 243 on the shoulder screws and tighten them with 30Nm.
Step 2. Adjust the stator knife so the gap between the rotating knives and
the stator is paper thin and can move freely.
