THERMOSALD ISC – MAINTENANCE & OPERATIONS MANUAL Rev. 2010 / 03

(Includes all previous models)

Manuale cod.: 3ES080x_V5.1_MU_EN Page Nr. 34 Tot. Nr . 47

6 SPECIFICATIONS

6.1 SPECIFICATIONS – MODELS WITH CONTROL OF THE SECONDARY

LOGIC CIRCUIT SUPPLY ( CN2 ) 230Vac +/- 10% ( 0.1 A absorption )

POWER CIRCUIT SUPPLY MODEL SECONDARY 10 - 100V

MAXIMUM SHORT CIRCUIT CURRENT MOD. 60 A 150 AMP

MAXIMUM SHORT CIRCUIT CURRENT MOD. 90 A 260 AMP + 10%

MAINS FREQUENCY 50 - 60 Hz (automatic changing )

DIGITAL CONTROLS 24 VDC (12 mA max. absorption )

OUTPUT SEALING FAULT CONTACT 250 V 8A cosΦ = 1 250V 5A cosΦ = 0.4

ACCURACY ≅ +/- 1 °C

PRE-HEATING TEMPERATURE can be set from display console, 0 - 250 °C

SEALING TEMPERATURE can be set from display console, 0 - 250 °C

SEALING TIME determined by PLC ( or precision timer)

COOLING TIME determined by PLC ( or precision timer)

AMBIENT TEMPERATURE 0° C +50° C

LEVEL OF BOARD PROTECTION IP00

LEVEL OF DISPLAY CONSOLE PROTECTION IP65

POWER ASSEMBLY WEIGHT 1,6 Kg

PANEL WEIGHT 0.2 Kg

PANEL-POWER ASSEMBLY EXTENSION WEIGHT 0.2 Kg

6.2 SPECIFICATIONS – MODELS WITH CONTROL OF THE PRIMARY
