THERMOSALD ISC – MAINTENANCE & OPERATIONS MANUAL Rev. 2010 / 03
(Includes all previous models)
Manuale cod.: 3ES080x_V5.1_MU_EN Page Nr. 36 Tot. Nr . 47
ANNEX A – TYPICAL SEALING CYCLE
NOTE - The sealing cycle showed bottom is only for example and not a standard cycle to follow
everytime. From experience we have learnt that it’s necessary modify the cycle depending on materials,
dimensions, speeds and else. For other informations don’t exitate to contact our technical office.
SEALING CYCLE
PRE-HEATING
SIGNAL
(IN THERMOSALD)
SEALING SIGNAL
(IN THERMOSALD)
closed
FILM GRIPPER JAWS
open
closed
BAND SEALERS
open
COOLING
FILM FEED
