3M™ Overhead Projector 1700 Series Illustrated Parts Breakdown
© 3M 2005. All Rights Reserved. 9
Arm and Focus Assembly (Gray color) Parts List
(Serial Number 170006497 and below)
Item
No.
3M
Part Number
Description Qty.
1 78-8114-8983-6 Shim, Head Leveling 1
2 78-8120-3045-6 Arm, Focus 1
3 (Not Available) Spring, Leaf 1
4 78-8120-3069-6 Pad, Rear 1
5 78-8120-3047-2 Pad, Friction, Lower 1
6 78-8120-3048-0 Knob, Gear, Focus 1
7 78-8120-3046-4 Cap, Focus Arm 1
8 78-8079-8744-7 Rack, Focus 1
9 26-1009-3653-8 Cap, Post 1
10 78-8120-4017-4 Pad, Friction. Upper 1
