3M Overhead Projector 1700 Series Illustrated Parts Breakdown
© 3M 2005. All Rights Reserved. 3
Section 0. Machine Overview
Head Assembly
(See Section 1)
Top Cover Assembly
(See Sections 6 and 7)
Arm and Focus Assembly
(See Sections 2, 3 and 4)
Control Module
(See Section 9)
Post
Assembly
(See
Section 5)
Base Enclosure
(See Section 8)
Lamp Housing (Single)
(See Section 10)
Lamp Housing (Dual)
(See Section 11)
Cooling Fan
(See Section 12)
Accessories
(See Section 13)
Wire Jumpers
(See Section 14)
Hardware Kit
(See Section 15)
